Qtech QSW-2870 [132/230] Configure multicast vlan copy
![Qtech QSW-2870 [132/230] Configure multicast vlan copy](/views2/1596592/page132/bg84.png)
Chapter7 Security Configuration
6-5
Parameter
Description
Value
ip
forward multicast data
according to IP address
-
mac
forward multicast data
according to MAC address
-
6.2.3 Configure Multicast VLAN Copy
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Objective
Step
Globally enable
IGMP Snooping
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping start to globally enable IGMP Snooping;
3. Done.
Create
multicast VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of vlan vlan-list to create VLAN which should be enabled
IGMP Snooping;
3. Use command of igmp-snooping mvlan vlan-id to create corresponding
multicast VLAN and enter the multicast VLAN configuration view;
4. Done.
Configure
multicast data
forwarding mode
of multicast VLAN
to be IP
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
VLAN configuration view;
3. Use command of igmp-snooping forwarding-mode ip to configure
multicast data forwarding mode to be IP;
4. Done.
Enable
multicast copy
function of
multicast VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
VLAN configuration view;
3. Use command of igmp-snooping multicast-vlan enable to enable
multicast VLAN copy function;
4. Done.
Configure user
VLAN
1. Use command of configure to enter the Global Configuration View;
2. Use command of igmp-snooping mvlan vlan-id to enter the multicast
VLAN configuration view;
3. Use command of igmp-snooping multicast user-vlan vlan-list to
configure user VLAN;
4. Done.
Configure
1. Use command of configure to enter the Global Configuration View;
