Chapter2 Layer 2 Ethernet Configuration
2-19
Objective
Step
Configure the
threshold value
of active
interface
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface trunk trunk-id to enter the Trunk Interface
Configuration View;
3. Use command of active-linknumber max link-number to configure the
high threshold value of active interface;
4. Done.
Configure the low threshold value of active interface.
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface trunk trunk-id to enter the Trunk Interface
Configuration View;
3. Use command of active-linknumber min link-number to configure the
low threshold value of active interface;
4. Done.
(Optional)
Configure
system LACP
priority
1. Use command of configure to enter the Global Configuration View;
2. Use command of lacp priority system-priority to configure system
LACP priority;
3. Done.
(Optional)
Configure
interface LACP
priority
1. Use command of configure to enter the Global Configuration View;
2. Use command of interface interface-type interface-number to enter the
Interface Configuration View;
3. Use command of lacp priority port-priority to configure interface LACP
priority;
4. Done.
Appendix List:
Parameter
Description
Value
trunk-id
trunk ID
integer with range of 1~8
interface-number
specify the observed Ethernet
interface number
integer, <1-8>/<0-4>/<1-48>
link-number
specify link aggregation active
interface high and low threshold
value
integer with range of 1~8, active
interface number default high
threshold value to be 8, active
interface number default low
threshold value to be 1
system-priority
specify system LACP priority
integer with range of 0~65535,
default system LACP priority to be
32768
port-priority
specify interface LACP priority
integer with range of 0~65535,
