Chapter8 Reliability Configuration
8-16
Parameter
Description
Value
hello-interval
STP hello message interval
to be from 1 to 10, unit: second
default
Default interval
2s
max-age
STP max aging time
to be from 6 to 40, unit: second
default
Default max aging time
20s
max-hop
STP max hop
to be from 4 to 30, unit: hop
default
Default max hop
20hops
instance-id
STP instance ID
to be from 1 to 63
priority
Interface priority
to be from 0 to 240, step by 16
default
Default value
128
path-cost
Port cost
to be from 0 to 200000
default
Default value
0
transmit-limit
Times of sending hello packet
to be from 1 to 255, unit: times
default
Default value
3times
cost
Interface path cost
to be from 0 to 200000
default
Default value
0
{ dot1t |
dot1d-1998 }
dot1t means IEEE 802.1t standard,
dot1d-1998 means IEEE 802.1D standard
-
migration-time
STP protocol migration time
to be from 1 to 10, unit: second
default
Default value
3s
interface-num
ber
Ethernet interface number
to be from <1-12>/<1-18>
trunk-number
Trunk interface number
to be from 1 to 128
8.2.6 Configure MSTP Protection Function
Background Information
BPDU protection
For the access layer device, the access interface usually connects with user
terminal (such as PC) or file server. At this time, the access interface can be
configured the as edge interface to realize interface fast switching. Under normal
circumstances, the edge interface will not receive BPDU message of STP. But if
anyone forges configuration message and attacks switch maliciously. When the
edge interface receives the configuration message, system will configure these
interfaces to be non-edge interface automatically and will calculate STP again.
This will results in network topology concussion. BPDU protection function can
prevent this network attack.
