Chapter2 Layer 2 Ethernet Configuration
2-13
Objective
Step
Parameter
Add/modify
address item
1. Use command of configure to enter
the Global Configuration View;
2. Use the following command:
mac-static vlan-id mac-address
fastethernet interface-number
vlan-id VLAN: integer with range
of 1~4094
mac-address: static MAC address,
form as AA:BB:CC:DD:EE:FF, A~F is
one hex number
interface-number: Ethernet
interface number, integer with range
of <1-8>/<0-4>/<1-48>
2.3.2 Configure System MAC Address Aging Time
Background
The appropriate aging time can realize the MAC address aging function effectively.
The longer or shorter aging time configured by user may result in that Switch will
broadcast many data messages which cannot find destination MAC address and it will
influence the running performance of Switch. If user configures the aging time too long,
Switch may save many old MAC address items and this will exhaust MAC address
table resources and cause that the Switch cannot update MAC address table
according to the changes in the network. If user configures the aging time too short,
Switch may delete effective MAC address item.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
Once the system is reset, dynamic list will be lost, but the stored static list and black
hole list will not be aged and lost.
Objective
Step
Parameter
Configure
the aging time
of MAC
address table
item
1. Use command of configure to
enter the Global Configuration
View;
2. Use command of mac
aging-time aging-time.
default of system dynamic MAC address
table item to be 300s
aging-time: integer with range of
60~630, unit: second
Notice:
