Chapter7 Security Configuration
6-3
Support IGMP query function.
Support IGMP message suppression.
Support interface fast leave.
Aging time of routing interface can be configured.
The maximum response interval of group member can be configured.
Multicast policy can be configured.
Router Alert option can be configured.
The source IP address of sending IGMP message can be configured.
Support IGMP Proxy function.
Support Controllable Multicast
Controllable multicast is a part of the IPTV multicast scheme. It is mainly applied
in the multicast environment of Layer-2 to control program number of IPTV and to
ensure the quality of service for the majority of users.
This characteristic has the following advantage.
Precise control of multicast service
Ensure the quality of service for the majority of users.
Reduce the harm of multicast attack to a certain extent.
6.2.2 Configure Static Layer 2 Multicast
Background
In Metro Ethernet, when user host needs to receive multicast data flow of some
multicast group, interface can be configured to join in the multicast group.
Purpose
After configuring this function, user can receive registered multicast data flow stably
and timely for long time.
Procedure
According to the different purposes, execute corresponding step. Please refer to the
following table.
