Chapter2 Layer 2 Ethernet Configuration
2-33
Objective
Step
3. Use command of statistic { enable | disable } to enable or disable
VLAN or VLANIF traffic statistics switch;
4. Done.
Clear specified
VLAN statistics
information
1. Use command of configure to enter the Global Configuration View;
2. Use command of reset vlan vlan-id statistic to clear specified VLAN
statistics information;
3. Done.
Check VLAN
configuration
information
divided based on
MAC address
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View, Use
command of interface fastethernet interface-number or interface eth-
trunk trunk-number to enter the Interface Configuration View or keep the
current Privilege User View;
2. Use command of show mac-vlan or use command of show mac-vlan
vlan-id or use command of show mac-vlan interface to check VLAN
configuration information divided based on MAC address;
3. Done.
Check VLAN
configuration
information
divided based on
IP sub-network
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View, Use
command of interface fastethernet interface-number or interface eth-
trunk trunk-number to enter the Interface Configuration View or keep the
current Privilege User View;
2. Use command of show ip-subnet-vlan or use command of show ip-
subnet-vlan vlan-id or use command of show ip-subnet-vlan interface to
check VLAN configuration information divided based on IP sub-network;
3. Done.
Check VLAN
configuration
information
divided based on
protocol
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View, Use
command of interface fastethernet interface-number or interface eth-
trunk trunk-number to enter the Interface Configuration View or keep the
current Privilege User View;
2. Use command of show protocol-vlan or use command of show
protocol-vlan protocol-index or use command of show protocol-vlan
interface to check VLAN configuration information divided based on
protocol;
3. Done.
Check VLAN
interface
configuration
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface vlan vlan-id to enter the VLANIF Configuration View
or keep the current Privilege User View;
2. Use command of show interface vlan vlan-id config or use command
