Chapter7 Security Configuration
6-12
Objective
Step
multicast VLAN
configuration file
information
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping mvlan to display IGMP
Snooping multicast VLAN configuration file information;
3. Done.
Check IGMP
Snooping router
interface
configuration file
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping uplinkport to display IGMP
Snooping router interface configuration file information ;
3. Done.
Check IGMP
Snooping table
information of all
or designated
interface or
designated
VLAN egress
interface
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping egress-port or show igmp-
snooping egress-port mvlan vlan-id or show igmp-snooping egress-port
interface fastethernet interface-number to display IGMP Snooping egress
interface table information;
3. Done.
Check IGMP
Snooping
multicast group
table information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping group to display IGMP
Snooping multicast group table information;
3. Done.
Check IGMP
Snooping
multicast source
table
information(only
effective of
version3)
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping source-address to display
IGMP Snooping multicast source table information;
3. Done.
Check IGMP
Snooping SSM
Map
configuration file
information
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-snooping ssm-mapping to diplay IGMP
