Chapter7 Security Configuration
6-13
Objective
Step
Snooping SSM Map configuration file information;
3. Done.
Check
channel
configuration of
controllable
multicast
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-control channel to display channel
configuration of controllable multicast;
3. Done.
Check
preview
template
configuration of
controllable
multicast
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-control preview-profile { NAME } to
display preview template configuration of controllable multicast;
3. Done.
Check
program
package
configuration
information of
controllable
multicast
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-control package { NAME } to display
program package configuration information of controllable multicast;
3. Done.
Check user
configuration
information of
controllable
multicast
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-control interface user to display
controllable user configuration file information based on interface;
3. Use command of show igmp-control interface-vlan user to display
controllable user configuration file information based on interface and VLAN;
4. Done.
Check online
user information
of controllable
multicast
1. Use command of disable to exit to the Common User View or use
command of configure to enter the Global Configuration View or use
command of interface fastethernet interface-number to enter the Interface
Configuration View;
2. Use command of show igmp-control interface online-user to display
online user information based on interface;
3. Use command of show igmp-control interface-vlan online-user to
display online user information based on interface and VLAN;
