1-3

Chapter1 Basic Configuration

When logging into QSW-2870 Switch through Console port, the user needs to

connect to the Console port of QSW-2870 front panel with a serial line.

Process

The processes of logging into QSW-2870 Switch through Console port are as follows:

 Connect the PC host and QSW-2870 Switch via a serial line, referring to

Figure 1-1 QSW-2870 Switch Login through Console Port;

 Start PC hyper terminal by selecting [Start → All Programs →

Accessories → Communication], there will be a pop-up window of

connection description;

 Create a new connection:

Input a name to the new created connection in the [Name] column,

e.g.,QSW-2870

 Connection port setting. Select COM1 or COM2 port according to

physical connection of serial line, and click <OK>
