Chapter7 Security Configuration
7-3
Objective
Procedure
|any)
filter filter number src-mac src-mac-address src-mask src-mac-mask
dst-mac dst-mac-address dst-mask dst-mac-mask
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
|any) (customer|provider)(any|<1-4094>|<1-4094>/<1-4094>) (any|<0-7>)
filter filter number src-mac src-mac-address src-mask src-mac-mask dst-
mac dst-mac-address dst-mask dst-mac-mask (customer|provider)
(any|<1-4094>|<1-4094>/<1-4094>) (any|<0-7>)
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
|any) eth-type (ip|arp|<0x1-0xfffe>)
filter filter number src-mac src-mac-address src-mask src-mac-mask
dst-mac dst-mac-address dst-mask dst-mac-mask eth-type (ip|arp|<0x1-
0xfffe>)
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
|any) provider (any|<1-4094>) (any|<0-7>) customer
(any|<1-4094>)(any|<0-7>)
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
|any) provider (<1-4094>/<1-4094>) (any|<0-7>) customer
(any|<1-4094>)(any|<0-7>)
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
|any) provider (any|<1-4094>) (any|<0-7>) customer
(<1-4094>/<1-4094>) (any|<0-7>)
filter filter number src-mac(src-mac-address/M|any) src-mask src-mac-
mask dst-mac dst-mac-address dst-mask dst-mac-mask provider
(any|<1-4094>) (any|<0-7>) customer
(any|<1-4094>)(any|<0-7>)
filter filter number src-mac (src-mac-address/M|any) src-mask src-mac-
mask dst-mac dst-mac-address dst-mask dst-mac-mask provider
(<1-4094>/<1-4094>) (any|<0-7>) customer
(any|<1-4094>)(any|<0-7>)
filter filter number src-mac (src-mac-address/M|any) src-mask src-mac-
mask dst-mac dst-mac-address dst-mask dst-mac-mask provider
(any|<1-4094>) (any|<0-7>) customer
(<1-4094>/<1-4094>)(any|<0-7>)
filter filter number mac (src-mac-address/M|any) (dst-mac-address/M
|any) provider (any|<1-4094>|<1-4094>/<1-4094>) (any|<0-7>) isid
(any|<1-16777215>)
filter filter number src-mac (src-mac-address/M|any) src-mask
src-mac-mask dst-mac dst-mac-address dst-mask dst-mac-mask
provider (any|<1-4094>|<1-4094>/<1-4094>) (any|<0-7>) isid
