Chapter7 Security Configuration
7-8
Objective
Procedure
|any) (icmp type|any) (icmp code|any)
filter filter number icmp src-ip src-ip-address src-mask { src-ip-mask
| any} dst-ip src-ip-mask dst-mask dst-ip-mask icmp type (icmp code
|any)
6. (Optional) Use the following commands to configure ACL rule
matching IGMP;
filter filter number igmp (src-ip-address/M |any) (dst-ip-address M
|any)
filter filter number igmp src-ip src-ip-address src-mask src-ip-mask
dst-ip src-ip-mask dst-mask dst-ip-mask
7. (Optional) Use the following commands to configure ACL rule
matching UDP;
filter filter number udp (src-ip-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any) (dst-ip-address/M |any) (<0-65535>|<0-
65535>/<0-65535>|any)|fragment
filter filter number udp src-ip { src-ip-address | any} src-mask
src-ip-mask (<0-65535>|any) dst-ip { src-ip-mask | any} dst-mask
{dst-ip-mask | any} (<0-65535>|any) |fragment
8. (Optional) Use the following commands to configure ACL rule
matching ARP;
filter filter number arp (request|response|any) (src-ip-address/M |any)
(dst-ip-address/M |any)
filter filter number arp (request|response|any) src-ip src-ip-address
src-mask { src-ip-mask | any} dst-ip src-ip-mask dst-mask dst-ip-mask
9. End.
Configure layer3 ACL
action
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to enter Layer3 ACL
Configuration View;
3. Use the following commands to configure ACL action;
filter rule-number action { permit | deny }
filter rule-number action redirect cpu
filter rule-number action mirror cpu
filter rule-number action mirror group group-number
filter rule-number action redirect { fastethernet | eth-trunk } slot/port
filter rule-number action redirect eth-trunk trunk number
filter rule-number action redirect ip-nexthop ip-address
filter rule-number action redirect ip-multihop ip-address ip-address
filter rule-number action redirect ip-multihop ip-address ip-address
ip-address
filter rule-number action redirect ip-multihop ip-address ip-address
