Chapter7 Security Configuration
7-20
Objective
Procedure
information
reset counter filte-list acl-number filter filter-number { in | out }
reset counter filte-list acl-number filter filter-number port fastethernet
slot-number port-number { in | out }
reset counter filte-list acl-number filter filter-number port eth-trunk
trunk-number { in | out }
reset counter filte-list acl-number filter filter-number vlan VLANID { in |
out }
3. End.
Delete ACL
action
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to enter ACL Configuration
View;
3. Use command of no filter rule-number action to delete ACL
corresponding action;
4. End.
Delete ACL rule
1. Use command of configure to enter Global Configuration View;
2. Use command of filter-list acl-number to enter ACL Configuration
View;
3. Use command of no filter rule-numbe to delete ACL rule;
4. End.
Check ACL
configuration
information
1. Use command of disable to exit Normal User View; or use command
of configure to enter Global Configuration View; or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View; or use command of filter-list
acl-number to enter ACL Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show filter-list or show filter-list acl-number to
display ACL configuration information;
3. End.
Check ACL
configuration file
information
1. Use command of disable to exit Normal User View; or use command
of configure to enter Global Configuration View; or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View; or use command of filter-list
acl-number to enter ACL Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show filter-list config to display ACL configuration
file information;
3. End.
Check ACL
statistic
information
1. Use command of disable to exit Normal User View; or use command
of configure to enter Global Configuration View; or use command of
interface fastethernet interface-number or interface eth-trunk
