Chapter8 Reliability Configuration
8-33
Objective
Procedure
trunk-number to enter Interface Configuration View, or no use any command
to keep current Privileged User View;
2. Use command of debug rlink { receive | send | timer | linkchange |
all } to enable RLINK debug function;
3. End.
Disable
RLINK debug
function
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of no debug rlink { receive | send | timer | linkchange |
all } to disable RLINK debug function;
3. End.
Enable
MLINK debug
function
1. Use command of disable to exit to Normal User View, or no use any
command to keep current Privileged User View;
2. Use command of debug mlink { linkchange | all } to enable MLINK
debug function;
3. End.
Disable
MLINK debug
function
1. Use command of disable to exit to Normal User View, or no use any
command to keep current Privileged User View;
2. Use command of no debug mlink { linkchange | all } to disable MLINK
debug function;
3. End.
Check RLINK
configuration file
information
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show rlink config to display configuration file
information of double uplinks redundancy function;
3. End.
Check
information of all
or designated
RLINK group
1. Use command of disable to exit to Normal User View, or use command
of configure to enter Global Configuration View, or use command of
interface fastethernet interface-number or interface eth-trunk trunk-
number to enter Interface Configuration View, or no use any command to
keep current Privileged User View;
2. Use command of show rlink group [ rlink-group-number ] to display
information of all or designated RLINK group;
3. End.
Check RLINK
1. Use command of disable to exit to Normal User View, or use command
