Chapter1 Basic Configuration
1-37
Device starts up in normal;
Device login correct;
If switch config file upload is required, it is necessary to save config file in
advance to guarantee there is file „startcfg‟ under switch Flash.
Purpose
To implement file upload through device serial port with operation introduced in this
section.
Process
According to the different purposes, execute corresponding step. Please refer to the
following table.
Purpose
Step
Upload file
to device
via serial
port
1. Use command of configure to enter the Global Configuration View;
2. Use command of zmodem put localfile filename or use command of
zmodem put config to upload file to device via serial port;
3. Done.
Appended List:
Parameter
Description
Value
filename
Designated local file name to be
uploaded
String for with length 1~63
1.4.3.3 Zmodem Download File
Background Information
It is not suggested to process operation for file download/upload with large file
transmission, due to its limited serial port transmission rate.
Precondition
Device starts up in normal;
Device login correct;
If switch config file download is required, it is necessary to save config file in
advance to guarantee there is file „startcfg‟ under switch Flash.
Purpose
