Chapter2 Layer 2 Ethernet Configuration
2-36
SwitchA(config)#interface fastethernet 1/0/1
SwitchA(config-ge1/0/1)#port hybrid vlan 100 untagged
SwitchA(config-ge1/0/1)#port hybrid pvid 100
SwitchA(config-ge1/0/1)#quit
SwitchA(config)#interface fastethernet 1/0/2
SwitchA(config-ge1/0/2)#port hybrid vlan 100 untagged
SwitchA(config-ge1/0/2)#port hybrid pvid 100
SwitchA(config-ge1/0/2)#quit
SwitchA(config)#interface fastethernet 1/0/3
SwitchA(config-ge1/0/3)#port hybrid vlan 100 untagged
SwitchA(config-ge1/0/3)#port hybrid pvid 100
SwitchA(config-ge1/0/3)#quit
SwitchA(config)#
//Create VLAN200 and enter its configuration view.
SwitchA(config)#interface vlan 200
SwitchA(config-vlan-200)#
//Configure VLAN200 description information to be Market200.
SwitchA(config-vlan-100)#description Market200
//Add interface Ge1/0/4 and Ge1/0/5 into VLAN100 and configure the VLAN200 to be
the PVID of interface Ge1/0/4 and Ge1/0/5.
SwitchA(config-vlan-100)#quit
SwitchA(config)#
SwitchA(config)#interface fastethernet 1/0/4
SwitchA(config-ge1/0/4)#port hybrid vlan 200 untagged
SwitchA(config-ge1/0/4#port hybrid pvid 200
SwitchA(config-ge1/0/4)#quit
SwitchA(config)#interface fastethernet 1/0/5
SwitchA(config-ge1/0/5)#port hybrid vlan 200 tagged
SwitchA(config-ge1/0/5)#port hybrid pvid 200
SwitchA(config-ge1/0/5)#quit
2. Configure SwitchB.
//Create VLAN200 and enter its configuration view.
SwitchB#configure
%Enter configuration commands.End with Ctrl+Z or command “quit” & “end”
SwitchB(config)#interface vlan 202
