Chapter2 Layer 2 Ethernet Configuration
2-40
Objective
Step
Parameter
add } outer outervlan-id [nto1] priority outer-priority
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
[nto1]
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
[nto1] priority inner-priority
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
[nto1] delete outer
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
[nto1] priority inner-priority delete outer
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
[nto1] { replace | add } outer outervlan-id
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
[nto1] priority inner-priority { replace | add } outer outervlan-
id
translation-vlan map-index inner-vlan { vlan-id |
vlan-id1/vlan-id2 } inner-pri priority replace inner innervlan-id
{ replace | add } outer outervlan-id [nto1] priority
outer-priority
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority replace inner innervlan-id
priority inner-priority { replace | add } outer outervlan-id
[nto1] priority outer-priority
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority { replace | add } outer
outervlan-id [nto1]
translation-vlan map-index inner-vlan { vlan-id | vlan-
id1/vlan-id2 } inner-pri priority { replace | add } outer
outervlan-id priority outer-priority
translation-vlan map-index inner-vlan innervlan-id outer-
vlan { vlan-id | vlan-id1/vlan-id2 } delete { inner | outer }
[nto1]
translation-vlan map-index inner-vlan innervlan-id outer-vlan
{ vlan-id | vlan-id1/vlan-id2 } delete inner delete outer [nto1]
translation-vlan map-index inner-vlan innervlan-id
