Chapter4 Router Configuration
3-3
Option 3: router option used to specify the distributed network gateway network
for Client.
Option 6: DNS Server option used to specify the distributed DNS Server address
for Client.
Option 51: IP address lease option.
Option 53: DHCP message type option used to identify DHCP message type.
Option 55: request parameter list. Client uses this option to specify to obtain
which network configuration parameters from Server. This option content is the
value corresponding with the parameters required by Client.
Option 66: TFTP Server name option used to specify the distributed TFTP Server
domain name for Client.
Option 67: starting file name option used to specify the distributed starting file
name for Client.
Option 150: TFTP Server address option used to specify the distributed TFTP
Server address for Client.
Option 121: non-classification routing option. This option includes a group of
non-classification static routing (the mask of destination address is any value and
can divide sub-network by mask). After Client receives this option, Client will add
these static routing in routing table.
Option 33: static routing option. This option includes a group of classified static
routing (the mask of destination address is fixed to be a natural mask and cannot
divide sub-network). After Client receives this option, Client will add these static
routing in routing table. If Option121 exists, this option will be ignored.
More DHCP option introduction refers to RFC 2132.
DHCP Advantages and Disadvantages
DHCP uses Client/Server communication mode. All IP network configuration
parameters are managed by DHCP Server concentrated and DHCP Server is
responsible for dealing with the DHCP request of Client. Client will use the IP network
parameter distributed by Server to communicate.
