English | 15
Bosch Power Tools 2 609 140 809 | (25.3.11)
Technical Data
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 84 dB(A); Sound power level 95 dB(A).
Uncertainty K =3 dB.
Wear hearing protection!
Vibration total values (triax vector sum) determined accord-
ing to EN 60745:
Sanding: Vibration emission value a
h
=2.6m/s
2
, uncertainty
K=1.5m/s
2
Cutting with plunge cut saw blade: Vibration emission value
a
h
=13.1m/s
2
, uncertainty K=1.5 m/s
2
Cutting with segmential saw blade: Vibration emission value
a
h
=12.2m/s
2
, uncertainty K=1.5 m/s
2
Scraping: Vibration emission value a
h
=17.3m/s
2
, uncertain-
ty K=1.5 m/s
2
.
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of ex-
posure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working
period.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work
patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
Technical file at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
Leinfelden, 25.08.2010
Assembly
Battery Charging
f Use only the battery chargers listed on the accessories
page. Only these battery chargers are matched to the
lithium ion battery of your power tool.
Note: The battery is supplied partially charged. To ensure full
capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging procedure
does not damage the battery.
The battery is equipped with a NTC temperature control
which allows charging only within a temperature range of
between 0 °C and 45 °C. A long battery service life is
achieved in this manner.
Removing the Battery
To remove the battery 2, press the unlocking buttons 1 and
pull the battery out of the machine to the rear. Do not exert
any force.
Battery Charge-control Indication
The three green LEDs of the battery charge-control indicator
4 indicate the charge condition of the battery 2. For safety
reasons, it is only possible to check the status of the charge
condition when the machine is at a standstill.
To indicate the charge condition, press and hold button 3 of
the switched off machine.
Changing the Tool
f Before any work on the machine itself (e.g. mainte-
nance, tool change, etc.) as well as during transport
and storage, remove the battery from the power tool.
There is danger of injury when unintentionally actuating
the On/Off switch.
f Wear protective gloves when changing application
tools/accessories. Contact with the application tool/ac-
cessoriy can lead to injuries.
Cordless Multi-Cutter GOP 10,8 V-LI
Professional
Article number
3 601 H58 0..
Rated voltage
V= 10.8
No-load speed n
0
min
-1
5000–20000
Oscillation angle, left/right
°1.4
Weight according to
EPTA-Procedure 01/2003
kg 1.0
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
LED Capacity
Continuous lighting 3 x green ≥ 2/3
Continuous lighting 2 x green ≥ 1/3
Continuous lighting 1 x green <1/3
Flashing light 1 x green Reserve
OBJ_BUCH-630-006.book Page 15 Friday, March 25, 2011 10:17 AM
