D-EOMHP00706-14EN - 19/78
3.3.5 Compressor VFD LED
Mode
LED
Main chip is working correctly.
Flashing
Main chip is not working. Power is coming to chip.
Lights (not flashing)
Main chip is not working.
No lights
3.4 Available sensors
3.4.1 Pressure transducers
Two types of electronic sensors are used to measure suction, discharge and oil pressure on each circuit.
The range of each sensor is clearly indicated on the sensor casing. Discharge and oil pressures are
monitored using a sensor of the same range.
Description
Number of sensors
Type
Calibration
Cond Pr
1 per Ckt
500mV ~ 4500mV
Offset by set point
Offset by set point
Evap Pr
1 per Ckt
500mV ~ 4500mV
Offset by set point
Offset by set point
3.4.2 Temperature Sensors
The evaporator water sensors are installed in the entering and leaving side. An outdoor temperature
sensor is mounted inside the chiller. Additionally each circuit installs a suction and discharge
temperature sensors to monitor and control the superheated refrigerant temperatures.
On refrigerant-cooled inverters additional sensors immersed into the cooling plate measure the
temperature of the drives.
Description
Number of sensors
Type
Calibration
EWT
1 per Unit
NTC10K
Offset by set point
LWT
1 per Unit
NTC10K
Offset by set point
OAT
1 per Unit
NTC10K
Offset by set point
Deicer Temp
1 per Ckt
NTC10K
Offset by set point
Evap Gas Temp
1 per Ckt
NTC10K
Offset by set point
Suct Temp
1 per Ckt
NTC10K
Offset by set point
Disch Temp
1 per Comp
-
Offset by set point
Comp casing Temp
1 per Comp
-
Offset by set point
INV FIN Temp
1 per Comp
-
No calibration
3.4.3 Thermistors
Thermistors trip to a high value in case the motor temperature reaches a hazardous temperature.
3.4.4 Other sensors
Description
Number of sensors
Type
Calibration
INV Output current
1 per Comp
-
No calibration
