D-EOMHP00706-14EN - 9/78
1 Safety considerations
1.1 General
Installation, start-up and servicing of equipment can be hazardous if certain factors particular to the
installation are not considered: operating pressures, presence of electrical components and voltages and
the installation site (elevated plinths and built-up up structures). Only properly qualified installation
engineers and highly qualified installers and technicians, fully trained for the product, are authorized to
install and start-up the equipment safely.
During all servicing operations, all instructions and recommendations, which appear in the installation
and service instructions for the product, as well as on tags and labels fixed to the equipment and
components and accompanying parts supplied separately, must be read, understood and followed.
Apply all standard safety codes and practices. Wear safety glasses and gloves.
Use the proper tools to move heavy objects. Move units carefully and set them down gently.
1.2 Avoid electrocution
Only personnel qualified in accordance with IEC (International Electrotechnical Commission)
recommendations may be permitted access to electrical components. It is particularly recommended that
all sources of electricity to the unit be shut off before any work is begun. Shut off main power supply at
the main circuit breaker or isolator.
IMPORTANT: This equipment uses and emits electromagnetic signals. Tests have shown that the
equipment conforms to all applicable codes with respect to electromagnetic compatibility.
RISK OF ELECTROCUTION: Even when the main circuit breaker or isolator is switched off,
certain circuits may still be energized, since they may be connected to a separate power source.
RISK OF BURNS: Electrical currents cause components to get hot either temporarily or
permanently. Handle power cable, electrical cables and conduits, terminal box covers and motor
frames with great care.
ATTENTION: In accordance with the operating conditions the fans can be cleaned periodically. A
fan can start at any time, even if the unit has been shut down.
1.3 Safety Devices
Each unit is equipped with safety devices of three different kinds:
1.3.1 General safety devices
Safeties of this level of severity will shut down all the circuits and stop the entire unit. When a general
safety device is happen, a manual intervention on the unit will be required in order to re-establish the
normal operability of the machine. There are exceptions to this general rule in case of alarms linked to
temporary abnormal conditions.
Emergency Stop
