D-EOMHP00706-14EN - 56/78
7.3 Compressor alarm
Unless otherwise specified compressor alarm shouldn’t be triggered during compressor state is OFF.
7.3.1 Compressor alarm descriptions
Description
Type
Shut down
Reset
Note
Multi times High discharge gas temperature
Fault
Rapid
Manual
High comp. body temperature
Fault
Rapid
Manual
Inverter over current shutdown
Fault
Rapid
Manual
Imbalance inverter current
Fault
Rapid
Manual
Inverter alarm
Fault
Rapid
Manual
Discharge temperature sensor fault
Fault
Rapid
Manual
Compressor body temperature sensor fault
Fault
Rapid
Manual
7.3.2 Detailed compressor alarm
7.3.2.1 High discharge gas temperature
[Purpose]
For compressor protection
[Trigger]
Discharge gas temperature is higher than the limit.
[Action]
Compressor should take Rapid shutdown as an event. However, if it repeats 3 times on the same
compressor within a week it becomes an alarm.
[Reset]
This alarm can be cleared manually via the keypad or via BAS command if trigger conditions no longer
exists.
7.3.2.2 High compressor body temperature
[Purpose]
For compressor protection
[Trigger]
Compressor body temperature is higher than the limit.
[Action]
Rapid shutdown of compressor
[Reset]
This alarm can be cleared manually via the keypad or via BAS command if trigger conditions no longer
exists.
7.3.2.3 Inverter over current shut down
See Inverter over current shutdown / unload / inhibit load in circuit alarm.
