D-EOMHP00706-14EN - 32/78
Demand limit
R
W
Optional control. See section 8.5 Demand limit control
Noise reduction
R
W
Optional control. See section 8.2 Noise reduction mode
Noise reduction start tm
R
W
Optional control. See section 8.2 Noise reduction mode
Noise reduction end tm
R
W
Optional control. See section 8.2 Noise reduction mode
Noise reduction Cond tar offset
R
W*
Optional control. See section 8.2 Noise reduction mode
Noise reduction Evap tar offset
R
W*
Optional control. See section 8.2 Noise reduction mode
Rapid restore
R
W
Optional control. See section 8.11 Rapid Restore
RR max power failure tm
R
W
Optional control. See section 8.11 Rapid Restore
Water valve ctrl
R
W
Optional control. See section 8.10 Water valve control
4.5 Before operation
Make sure that the circuit breaker on the power supply panel of the unit is switched off.
4.5.1 Checks before initial start-up
After the installation of the unit, check follows before switching on the circuit breaker.
Items
Contents
Field wiring
Confirm that the field wiring between the local supply panel and the unit has been hooked up
according to the installation manual, wiring diagrams and European and national regulations.
Fuses or protection devices
Confirm that the size and type of the fuses or protection devices are specified in the installation
manual.
Earth wiring
Confirm that the earth wiring is done properly and that the earth terminals are tightened.
Internal wiring
Confirm the loose connections or damaged electrical components in the control box visually.
Fixation
Confirm that the unit is properly anchored. If not, it can be the causes of noise and vibration.
Damaged equipment
Confirm that there is no damaged part on the unit.
Refrigerant leak
Confirm that there is no leak from all connections. If the leak is found, contact your local dealer.
Oil leak
Confirm that there is no leak from compressor. If the leak is found, contact your local dealer.
Stop valves
Fully open all stop valves on liquid line, discharge and suction (if provided).
Air inlet / outlet to control
box and fin&tube coils.
Confirm that there is no obstruction to disturb air flow to the control box and fin&tube coils.
Power supply voltage
Confirm the power supply voltage on the local supply panel. Voltage should correspond to the
identification label on the unit.
Water pipe connection
Confirm that water can be provided to the unit properly.
4.5.2 Water supply
Confirm that the quality and volume of water described in the installation manual is provided to the unit.
And also, air should be purged from system completely. Finally make sure that water can circulate system
properly.
4.5.3 Power supply connection and crankcase heating
In order to avoid compressor damage, it is necessary to turn the crankcase heater on for at least 6 hours
prior to start compressor after a long period of standstill.
