D-EOMHP00706-14EN - 30/78
4.4 Operation settings
To make the unit working on purpose, the following items need to be set correctly. In particular, first two
items have to be set for all chillers. Other items are for optional controls. The following sections describe
how to deal with each parameter.
Items to be set for chiller control
Reference section #
Unit enabling control
5 Unit availability
Activate set point
6.1 LWT target setting
Pump selection
6.2 Pump control
Ice mode control
10.1 Ice mode
Noise reduction control
10.2 Noise reduction control
Unit current limit control
10.3 Unit current limit control
Flexible current limit control
10.4 Flexible current limit control
4-20mA Demand limit control
10.5 4-20mA Demand limit control
Unit capacity Network limit control
10.6 Network limit control
Soft load control
10.7 Soft load control
Unit capacity Network limit control
10.6 Network limit control
Water valve control
10.10 Water valve control
Rapid restore control
10.11 Rapid restore
Chiller network control
10.12 Chiller network control
All the set points required for above items can be accessed via the “VIEW/SET UNIT” – “SETUP”.
Menu Level 1
Menu Level 2
ENTER PASSWORD
Unit overview information
QUCIK MENU
VIEW / SET UNIT
--->
STATUS
SETUP
DATA
VIEW / SET CIRCUIT
COMMISSION UNIT
TIME UNTIL RESTART
ALARMS
SCHEDULED MAINTENANCE
ABOUT THIS CHILLER
DATA / TIME
Following list describes each set point under “SETUP”. “W*” under “write” column in the list means the
maintenance password is required to change values.
SETUP
read
write
Description, reference section
Unit enable
R
W
See section 5. Unit availability
Ctrl source
R
W
See section 5. Unit availability
Available mode
R
W*
See section 5. Unit availability
