D-EOMHP00706-14EN - 51/78
7.2 Circuit alarm
7.2.1 Circuit alarm descriptions
Description
Type
Shut down
Reset
Note
High discharge port temperature
Fault
Rapid
Manual
Mechanical High Pressure Switch
Fault
Rapid
Manual
Triggered regardless compressor state
High Cond Pr shut down
Fault
Rapid
Manual
Low Evap Pr shut down
Fault
Rapid
Manual
Low Evap Gas Temperature
Fault
Rapid
Manual
High Pr ratio shut down
Fault
Rapid
Manual
Multi times Low Pr diff. shut down
Fault
Rapid
Manual
No pressure change after start
Fault
Rapid
Manual
Cond Pr sensor fault
Fault
Rapid
Manual
Evap Pr sensor fault
Fault
Rapid
Manual
Deicer temp sensor fault
Fault /
Warning
Normal
Manual
Heating…Fault
Cooling…Warning
Suct temp sensor fault
Fault
Rapid
Manual
Evap gas temp sensor fault
Warning
-
Auto
ACS MB communication failure
Fault
Rapid
Auto
Modbus communication failure
Fault
Rapid
Auto
External I/O communication failure
Fault
Rapid
Auto
No pressure at start
Warning
-
Manual
High condenser pressure at start
Warning
-
Auto
7.2.2 Detailed Circuit alarms
7.2.2.1 High discharge port temperature
[Purpose]
Avoid damage to compressor (oil deterioration, high fluctuation of metal, motor).
[Triggers, Actions and Resets]
The Circuit takes rapid shutdown when the discharge port temperature becomes higher than the limit.
The Circuit takes unload or inhibit load sequence before it goes over the limit. Shutdown requires reset
manually. Unload and inhibit load is reset automatically when conditions are recovered.
7.2.2.2 Mechanical High Pressure Switch
[Purpose]
To avoid the circuit operates at over design pressure.
[Trigger]
HPS digital input is open
[Action]
Rapid shut down of circuit
[Reset]
