D-EOMHP00706-14EN - 57/78
7.3.2.4 Imbalance inverter current
[Trigger]
One of the motor current is extremely higher than other motor currents
Note: “INV current” use INV secondary current.
[Action]
Rapid shutdown of compressor
[Reset]
This alarm can be cleared manually via the keypad or via BAS command when compressor is off.
7.3.2.5 Inverter alarm
[Inverter alarm list]
Fault code
Description
Note
E5
Compressor motor lock
L0
Inverter system error
L4
Inverter fin temperature high
L5
Inverter compressor motor grounding or short circuit
L8
Inverter over current
L9
Start up error
P1
Power supply imbalance
P4
Inverter fin temperature sensor fault
PJ
Model setup problem
U1
Reverse phase, open phase
U2
Power supply insufficient
[Action]
Rapid shutdown of compressor
[Reset]
This alarm can be cleared manually via the keypad or via BAS command if INV no longer requires stop.
7.3.2.6 Discharge temperature sensor fault
[Trigger]
Out of range for 1second
[Action]
Rapid shutdown of compressor
[Reset]
This alarm can be cleared manually via the keypad or via BAS command if the sensor is back in range for
5seconds.
7.3.2.7 Compressor body temperature sensor fault
[Trigger]
Out of range for 1second
[Action]
