Daikin EWAQ340GZXR [38/78] Oat reset

D-EOMHP00706-14EN - 38/78

--- For heating ---

6.1.2.4 OAT Reset

The Active Leaving Water variable is adjusted by the OAT.

--- For cooling ---

Active LWT target

LWT set point

- Max Reset

LWT set point

Max Reset

20mA (DC)

Reset Signal (mA)

4mA (DC)

Active LWT target

LWT set point

+ Max Reset

LWT set point

Max Reset

20mA (DC)

Reset Signal (mA)

4mA (DC)
