D-EOMHP00706-14EN - 43/78
7 Alarm
7.1 Unit alarm
7.1.1 Unit alarm descriptions
Description
Type
Shut down
Reset
Note
Phase Volts loss / GFP fault
Fault
Rapid
Auto
Water temperature freeze shut down
Fault
Rapid
Manual
Water flow loss
Fault
Rapid
Manual
This alarm can be active regardless unit state.
Just depends on pump state
Water pump freeze protection
Fault
-
Auto
This alarm can be active only when unit state
is OFF.
Water pump hot water protection
Fault
-
Auto
This alarm can be active only when unit state
is OFF.
Water temp inverted
Fault
Normal
Manual
Low OAT lock out
Fault /
Warning
Normal
Auto
Unit AUTO…Fault
Unit OFF…Warning
High OAT lock out
Fault /
Warning
Normal
Auto
Unit AUTO…Fault
Unit OFF…Warning
LWT sensor fault
Fault
Rapid
Manual
This alarm can be active regardless unit state.
EWT sensor fault
Fault
Normal
Manual
This alarm can be active regardless unit state.
OAT sensor fault
Fault
Normal
Manual
Emergency stop
Fault
Rapid
Manual
This alarm can be active regardless unit state.
External alarm
Fault
Rapid
Manual
This alarm can be active regardless unit state.
Bad demand limit input
Warning
-
Auto
Bad LWT reset point
Warning
-
Auto
Bad unit current reading
Warning
-
Auto
Bad flexible current limit input
Warning
-
Auto
Chiller network communication failure
Warning
-
Auto
This alarm can be active regardless unit state.
