D-EOMHP00706-14EN - 20/78
3.5 Available Controls
3.5.1 Evaporator pumps
The controller can regulate one or two evaporator pumps and takes care of automatic change-over
between pumps. It’s also possible to prioritize the pumps and temporarily disable one of the twos. The
controller is also able to control the pump speeds if the pumps are equipped with inverters.
3.5.2 Compressors
The controller can regulate maximum twelve compressors installed on one or two independent
refrigerant circuit (maximum six compressors per circuit). All the safeties of each compressor will be
managed by the controller. Embedded inverter safeties are handled by the inverter onboard electronic
and only notified to the UC.
3.5.3 Expansion Valve
The controller can regulate an electronic expansion valve per each refrigerant circuit. Microtech® III
embedded logic will always guarantee the best operation for the refrigerant circuit.
3.6 Customer Terminal Block Connections
3.6.1 General description
The contacts below are available at the user’s terminal block referred as MC24 or MC230 in the wiring
diagram. The following table summarizes the connections at the user’s terminal block.
Description
Terminals
Notes
Flow Switch (mandatory)
708-724 (MC24)
24 Vdc digital input
Double setpoint
703-728 (MC24)
24 Vdc digital input
Current limit enable
884-885 (MC24)
24 Vdc digital input
External Fault
883-884 (MC24)
24 Vdc digital input
Rapid Restart Enable (optional)
-
24 Vdc digital input
Back-up chiller (optional)
-
24 Vdc digital input
LOC/BMS selection (optional)
-
24 Vdc digital input
On-Off Remote
-
230 Vac digital input
General Alarm
525-526 (MC230)
NO digital output (24…230 Vac ext supply)
Compressor #1 status
-
NO digital output (24…230 Vac ext supply)
Compressor #2 status
-
NO digital output (24…230 Vac ext supply)
Alarm Circuit #1 (optional)
-
NO digital output (24…230 Vac ext supply)
Alarm Circuit #2 (optional)
-
NO digital output (24…230 Vac ext supply)
Evaporator Pump #1 start
527-528 (MC230)
NO digital output (24 Vdc internal supply)
Evaporator Pump #2 start
530-531 (MC230)
NO digital output (24 Vdc internal supply)
Demand Limit
888-889 (MC24)
4-20 mA analog input
Current Limit (optional)
889-890 (MC24)
4-20 mA analog input
Setpoint Override
886-887 (MC24)
4-20 mA analog input
3.6.1.1 Flow Switch
Although the flow switch is offered as an optional, it is mandatory to install one and connect it to the
digital input terminals in order to enable chiller operation only when a minimum flow is sensed.
