D-EOMHP00706-14EN - 75/78
9.4 Alarm limit set points
All set points can be accessed via key pad with certain password. Those set points do not require
controller reset to activate new setting. Direction will be [Main menu] / [Alarms] / [Alarm limits].
Name
Class
Unit
Default
Min.
Max.
Note
Water freeze
Unit
°C
2.8
2.8
6.0
Water freeze w/ glycol
Unit
°C
2.8
-18.0
6.0
With glycol
Water flow proof
Unit
Sec.
15
5
15
Recirc timeout
Unit
Min.
3
1
10
Low OAT lockout
Unit
°C
2.0
2.0
15.0
Low OAT lockout w/ VFD
Unit
°C
2.0
-20.0
15.0
With fan VFD
Low OAT lockout in heat
Unit
°C
-15.0
-15.0
0.0
For heating operation
High OAT lockout in heat
Unit
°C
25.0
10.0
25.0
For heating operation
Low evap gas temp
Circuit
°C
-3.5
-3.5
5.0
Low evap gas temp w/ glycol
Circuit
°C
-3.5
-25.0
5.0
With glycol
External fault cfg
Unit
-
-
-
-
9.5 Sensor calibration set points
All set points can be accessed via key pad with certain password. Those set points do not require
controller reset to activate new setting. Direction will be [Main menu] / [View/Set Unit] / [Setup] /
[Calibrate sensors] or [Main menu] / [View/Set Circuit] / [Setup] / [Calibrate sensors].
Name
Class
Unit
Default
Min.
Max.
Note
EWT offset
Unit
°C
0.0
-5.0
5.0
LWT offset
Unit
°C
0.0
-5.0
5.0
With glycol
OAT offset
Unit
°C
0.0
-5.0
5.0
Cond pr offset
Circuit
kPa
0
-100
100
Evap pr offset
Circuit
kPa
0
-100
100
Deicer temp offset
Circuit
°C
0.0
-5.0
5.0
With fan VFD
Evap gas temp offset
Circuit
°C
0.0
-5.0
5.0
For heating operation
Suct temp offset
Circuit
°C
0.0
-5.0
5.0
For heating operation
Disch temp offset
Comp
°C
0.0
-5.0
5.0
Casing temp offset
Comp
°C
0.0
-5.0
5.0
With glycol
9.6 Test mode set points
All outputs except for compressor starter outputs should be manually controllable via test mode set
points. For each output, there should be a set point that is visible and changeable only when test mode is
enabled.
For Unit level outputs test mode is enabled only when the unit mode is “Test”. For Circuit outputs test
mode is enabled when either unit mode is Test, or the circuit mode is “Test”. When the unit mode is no
longer Test, all unit test mode set points should be changed back to their ‘off’ values. The same should
occur for circuit test mode set points. When test mode is no longer enabled for the circuit, all the circuit
test mode set points for that circuit should be changed back to their ‘off’ values.
