Daikin EWAQ340GZXR [27/78] Controller ip setup
![Daikin EWAQ320GZXR [27/78] Controller ip setup](/views2/1675086/page27/bg1b.png)
D-EOMHP00706-14EN - 27/78
for US chillers.
Comm. Module1
Automatically detected.
BACNET IP, BACNET MSTP,
LON, MODBUS, AWM
Comm. Module2
Comm. Module3
Modification to any of these value will require to be acknowledged to the controller by setting
“Apply Changes = Yes”. This will cause a controller reboot!
4.3.2 Controller IP setup
The Microtech ® III controller has an embedded web server showing a replica of the onboard HMI
screens. To access this additional web HMI can be required to adjust the IP settings to match the settings
of the local network. This can be done in this page. Please contact your IT department for further
information on how to set the following setpoints. The controller also supports DHCP, in this case the
name of the controller must be used.
CTRLR IP SETUP
read
write
Apply Changes
R
W
DHCP
R
W
Actual IP Address
R
-
Actual Mask
R
-
Actual Gateway
R
-
Given IP Address
R
W
Given Mask
R
W
Given Gateway
R
W
Modification to any of these value will require to be acknowledged to the controller by setting
“Apply Changes = Yes”. This will cause a controller reboot!
4.3.3 Setup for BMS
The following set points have to be set based on customer requirements for enabling the unit working
with BMS.
4.3.3.1 LON setup
LON SETUP
read
write
Apply Changes
R
W
Module Status
R
-
Neuron ID
R
-
Max Send Time
R
W
Min Send Time
R
W
Receive Heartbeat
R
W
LON BSP
R
-
