D-EOMHP00706-14EN - 25/78
4.2 Menu navigation
The first column is the top level of the menu hierarchy. As the user makes selections in a column, they
move to the right. When no more menus exist in a path, selecting an option takes the user to the selected
screen. Some options are only visible when they can be selected as a result of unit configuration and user
password.
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
ENTER PASSWORD
Unit overview information
QUCIK MENU
VIEW / SET UNIT
--->
STATUS
SETUP
--->
CALIBRATE SENSORS
CHILLER NETWORK CTRL
DATA
VIEW / SET CIRCUIT
--->
CKT #n
--->
STATUS
SETUP
--->
CALIBRATE SENSORS
DATA
COMP #n
MANUAL CONTROL
COMMISSION UNIT
--->
CONFIGURATION
CTRLR IP SETUP
LON SETUP
BACNET IP SETUP
BACNET MSTP SETUP
MODBUS SETUP
AWM SETUP
MENU PASSWORD
TIME UNTIL RESTART
ALARMS
--->
ACTIVE ALARM
ALARM LOG
EVENT LOG
ALARM LIMITS
SCHEDULED MAINTENANCE
TEST I/O
--->
UNIT I/O TEST
CKT #1 I/O TEST
CKT #2 I/O TEST
ABOUT THIS CHILLER
DATA / TIME
