D-EOMHP00706-14EN - 72/78
9 Set Point Table
9.1 Chiller configuration set points
All set points can be accessed via key pad with certain password. Those set points require controller reset
to activate new setting. Direction will be [Main menu] / [Commission Unit] / [Configuration].
Name
Default
Range
Note
Voltage
400
208~230, 380, 400, 460
Frequency
50
50, 60
Unit type
Cool only
Cool only, Heat pump
Efficiency type
Hi Eff
Std Eff, Hi Eff
Number of Ckt
1
1,2
Ckt # Number of comps
3
3, 4, 5, 6
Need to be set for each
circuits
Ckt # Number of fans
3
3, 4, 5
Need to be set for each
circuits
Ckt # Liquid line SV
Disable
Enable, Disable
Need to be set for each
circuits
HPS setting
Normal
Normal, Higher limit
“Higher limit” will be used
only for US chillers.
Comm. Module1
Automatically
detected
BACNET IP, BACNET MSTP, LON,
MODBUS, AWM
Comm. Module2
Comm. Module3
9.2 Unit set points
All set points can be accessed via key pad with certain password. Those set points do not require
controller reset to activate new setting. Direction will be [Main menu] / [View/Set Unit] / [Setup].
Name
Class
Unit
Default
Min.
Max.
Note
Unit enable
Unit
-
Enable
Disable, Enable
Ctrl source
Unit
-
Local
Local, Network
Available mode
Unit
-
Cool / Heat
Cool/ Heat,
Cool/Heat/Ice w/glycol,
Test
For heat pump chiller
Available mode
Unit
-
Cool
Cool,
Cool w/glycol,
Cool/Ice w/ glycol,
Ice w/glycol,
Test
For cooling chiller
Max # ckts running
Unit
-
1
1
2
Sequence # C1
Unit
-
1
1
2
Sequence # C2
Unit
-
1
1
2
Chiller status after power failure
Unit
-
Enable
Enable, Disable
Pump ctrl
Unit
-
#1 only
#1 only,
#2 only,
Auto,
#1 primary,
#2 primary
Pump variable flow
Unit
-
No
No, Yes
Pump recur tm
Unit
Sec.
30
0
300
Cool LWT 1
Unit
°C
7.0
4.0
20.0
