D-EOMHP00706-14EN - 71/78
8.12.3.7 Next one to start, next one to stop
The master unit will manage which one should be next to start or stop based on the following table.
Priority
Next one to start
Next one to stop
1st
Highest unit sequence number
Lowest unit sequence number
2nd
Highest nominal capacity unit
Lowest nominal capacity unit
3rd
Least starts
Least starts
4th
Least run hours
Most run hours
5th
Highest network communication address
Lowest network communication address
8.12.4 Defrost
If the unit is in chiller network the defrost control of those units shall be limited to maintain certain
capacity.
8.12.5 Chiller network Status
The displayed chiller network status should be determined by the conditions in the following table.
Enum
Chiller network status
Conditions
0
In network
Chiller network set point is set to Enable and there is no communication failure of
chiller network
1
Disconnected
Chiller network set point is set to Disable
2
Comm fail
Chiller network set point is set to Enable and there is communication failure of
chiller network
