D-EOMHP00706-14EN - 39/78

--- For heating ---

Active LWT target

LWT set point

- Max Reset

LWT set point

Max Reset

Max Reset OAT

(Heating)

OAT

Start Reset OAT

(Heating)

Active LWT target

LWT set point

+ Max Reset

LWT set point

Max Reset

Start Reset OAT

(Cooling)

OAT

Max Reset OAT

(Cooling)
