Gigabyte MZ32-AR0 (rev. 1.0) [103/146] 3 5 9 fch ras options

- 103 - BIOS Setup

2-3-5-9 FCH RAS Options

Parameter

Description

FCH RAS Options

ALink RAS Support

Enable/Disable the ALink RAS Support.

Options available: Auto, Enabled, Disabled. Default setting is Auto.

Resetaftersyncood

EnablesABtoforwarddownstreamsync-oodmessagetosystem

controller.

Options available: Auto, Enabled, Disabled. Default setting is Auto.
