Gigabyte MZ32-AR0 (rev. 1.0) [36/146] 2 4 ast2500 super io configuration

BIOS Setup - 36 -

2-2-4 AST2500 Super IO Conguration

Parameter

Description

AST2500 Super IO

Conguration

Super IO Chip Displays the super IO chip information

Serial Port 1/2

Conguration

Press[Enter]forcongurationofadvanceditems.
