Gigabyte MZ32-AR0 (rev. 1.0) [98/146] 3 5 4 ac power loss options

BIOS Setup - 98 -

2-3-5-4 AC Power Loss Options

Parameter

Description

AC Power Loss Options

AC Loss Control

Selects the AC Loss Control Method.

Options available: Power Off, Power On, Last State.

Default setting is Last State.
