Gigabyte MZ32-AR0 (rev. 1.0) [106/146] 4 amd pbs menu

BIOS Setup - 106 -

2-4 AMD PBS Menu

AMD PBS Option menu displays submenu options for configuring the function of AMD PBS. Select a

submenu item, then press [Enter] to access the related submenu screen.

Parameter Description

RAS Press[Enter]forcongurationofadvanceditems.

SPI Locking

Enable/Disable SPI Locking for protect ROM part.

Options available: Enabled/Disabled. Default setting is Disabled.
