BIOS Setup - 96 -

2-3-5-2 USB Conguration Options

Parameter

Description

USBCongurationOptions

XHCI Controller 0/1 enable

Enable/Disable USB3 controller.

Options available: Auto, Enabled, Disabled. Default setting is Auto.

USB ecc SMI Enable Options available: Auto, Enable, off. Default setting is Auto.

MCH USB enable

Press[Enter]tocongureadvanceditems.



XHCI2 enable (Socket1)

– Enable/Disable USB3 controller.

– Options available: Auto, Enabled, Disabled. Default setting is

Auto.



XHCI3 enable (Socket1)

– Enable/Disable USB3 controller.

– Options available: Auto, Enabled, Disabled. Default setting is

Auto.
