- 19 - Hardware Installation
1-8 Internal Connectors
Read the following guidelines before connecting external devices:
•
First make sure your devices are compliant with the connectors you wish to connect.
•
Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
•
After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX 11) F_USB2
2) ATX_12V (for CPU) 12) COM2
3) ATX_12V (for Memory) 13) FP_1
4) CPU0_FAN 14) BP_1
5) SYS_FAN1 15) SPI_TPM
6) SYS_FAN2 16) IPMB
7) SYS_FAN3 17) LED_BMC
8) SYS_FAN4 18) BAT
9) SYS_FAN5
10) F_USB3
CPU
DIMM_P0_A1
DIMM_P0_A0
DIMM_P0_B0
DIMM_P0_B1
DIMM_P0_C0
DIMM_P0_C1
DIMM_P0_D0
DIMM_P0_D1
DIMM_P0_F0
DIMM_P0_F1
DIMM_P0_G0
DIMM_P0_G1
DIMM_P0_H0
DIMM_P0_H1
DIMM_P0_E0
DIMM_P0_E1
9
12
13
1
2
3
4
6
7
8
11
5
10
14
15
16
17
18
