- 11 - Hardware Installation
Internal I/O
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
10 x SlimSAS connectors
2 x M.2 slots
1 x CPU fan headers
5 x System fan headers
1 x USB 3.0 header
1 x USB 2.0 header
1 x COM_2 header
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1xClearCMOSjumper
1xBIOSrecoveryjumper
1 x Buzzer
Rear I/O
Connectors
3 x USB 3.0 ports
1 x VGA port
1 x Serial port
2 x RJ45 LAN ports
1 x MLAN port
1 x ID button with LED
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Board
Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Form Factor
E-ATX
305W x 330D (mm)
GIGABYTE reserves theright to makeany changes to the productspecications and product-related
information without prior notice.
