Default Settings:
Option Default Settings Related Information
System Name DWL-2210AP
“Setting the DNS Name” in
“Setting the Ethernet (Wired)
Interface”
User Name admin
The user name is read-only. It
cannot be modified.
Password admin
“Provide Administrator
Password and Wireless
Network Name” in “Configuring
Basic Settings” and “Setting the
Administrator Password”
Network Name (SSID)
Internal interface: “default”
Guest interface:
“default (guest)”
“Review / Describe the Access
Point” in “Configuring Basic
Settings.”
“Configuring Internal LAN
Wireless Settings” in “Setting
the Wireless Interface.”
“Configuring Guest Network
Wireless Settings” in
“Setting the Wireless Interface.”
Network Time
Protocol (NTP) “Enabling the Network Time
Protocol Server.”
None
IP Address 192.168.0.50
The default IP address is used
if you do not use a Dynamic Host
Configuration Protocol (DHCP)
server. You can assign a new
static IP address through the
Administration Web pages.
If you have a DHCP server on
the network, then an IP address
will be dynamically assigned by
the server at AP startup.
Option Default Settings Related
Information
Prelaunch Checklist
