111
Field Description
Key Type If WEP is enabled, specify the WEP key type:
• ASCII
• Hex
Characters Required Indicates the number of characters required in the WEP key.
The number of characters required updates automatically based
on how you set Key Length and Key Type.
WEP Key Enter a string of characters. If you selected “ASCII”, enter any
combination of 0-9. If you selected “HEX”, enter hexadecimal digits
(any combination of 0-9 and a-f or A-F). These are the RC4
encryption keys shared with the stations using the access point.
Example of Configuring a WDS Link
When using WDS, be sure to configure WDS settings on both access points on the
WDS link.
For example, to create a WDS link between a pair of access points “MyAP1” and “MyAP2”
do the following:
Configuring the Wireless Distribution System (WDS)
