151
Appendix A: Configuring Security Settings on Wireless Clients
Smart Card or other Certificate Properties Dialog
Validate Server Certificate Enable this option (click to check the box).
Certificates In the certificate list shown, select the certificate for this
client.
1. Configure the following settings on the Association tab on the Network Properties
dialog.
Logging on to the Wireless Network with a WPA Client Using a Certificate
WPA clients should now be able to connect to the access point using their TLS certificates.
The certificate you installed is used when you connect, so you will not be prompted for
login information. The certificate is automatically sent to the RADIUS server for
authentication and authorization.
Association Tab
Network Authentication WPA
Data Encryption TKIP or AES depending on how this option is configured
on the access point.
Note: When the Cipher Suite on the access point is set
to “Both”, then TKIP clients with a valid TKIP key and
AES clients with a valid CCMP (AES) key can associate
with the access point. For more information, see
Administrators Guide and Online Help on the access
point.
2. Configure these settings on the Authentication tab.
3. Click Properties to bring up the Smart Card or other Certificate Properties dialog and
enable the “Validate server certificate” option.
4. To complete the client configuration you must now obtain a certificate from the RADIUS
server and install it on this client. For information on how to do this see “Obtaining a
TLS-EAP Certificate for a Client” in this manual.
Click OK on all dialogs to close and save your changes.
Authentication Tab
Enable IEEE 802.1x
authentication for this network Enable (click to check) this option.
EAP Type Choose Smart Card or other Certificate.
