60
Configuring “Guest” Network Wireless Settings
The Guest Settings describe the MAC Address (read-only) and wireless network
name (SSID) for the Guest Network as described below. Configuring an access point
with two different network names (SSIDs) allows you to leverage the Guest interface
feature on the D-Link DWL-2210AP. For more information, see “Setting up Guest
Access” in this manual.
MAC Address Shows the MAC address for the Guest interface for this access
point. This is a read-only field that you cannot change.
Although this access point is physically a single device, it can
be represented on the network as two or more nodes each with
a unique MAC Address. This is accomplished by using multiple
Basic Service Set Identifiers (BSSID) for a single access point.
The MAC address(es) shown for the “Guest” access point is the
BSSID(s) for the “Guest” interface.
SSID Enter the SSID for the guest network.
The Service Set Identifier (SSID) is an alphanumeric string of up
to 32 characters that uniquely identifies a wireless local area
network. It is also referred to as the Network Name. There are
no restrictions on the characters that may be used in an SSID.
For the guest network, provide an SSID that is different from the
internal SSID and easily identifiable as the “guest” network.
Field Description
Updating Settings
To apply your changes, click Update.
