D-Link DWL-2200AP [58/192] Configuring the radio interface
![D-Link DWL-2200AP [58/192] Configuring the radio interface](/views2/1044822/page58/bg3a.png)
58
MAC Addresses
(Shown on two-radio AP only)
Mode The Mode defines the Physical Layer (PHY) standard
being used by the radio.
Select one of these modes:
• IEEE 802.11b
• IEEE 802.11g
Channel Select the Channel. The range of channels and the
default is determined by the Mode of the radio interface.
The Channel defines the portion of the radio spectrum
the radio uses for transmitting and receiving. Each
mode offers a number of channels, dependent on
how the spectrum is licensed by national and
transnational authorities such as the Federal
Communications Commission (FCC) or the
International Telecommunication Union (ITU-R).
The default is “Auto”, which picks the least busy
channel at startup time.
Configuring the Radio Interface
The radio interface allows you to set the radio Channel and 802.11 mode as described
below.
Field Description
Indicates the Media Access Control (MAC) addresses
for the interface.
A MAC address is a permanent, unique
hardware address for any device that represents an
interface to the network. The MAC address is assigned
by the manufacturer. You cannot change the MAC
address. It is provided here for informational purposes
as a unique identifier for an interface.
Setting the Wireless Interface
