159
Appendix A: Configuring Security Settings on Wireless Clients
The Welcome screen for the Certificate Server is displayed in the browser.
3. Click “Request a certificate” to get the login prompt for the RADIUS server.
4. Provide a valid user name and password to access the RADIUS server.
The user name and password you need to
provide here is for access to the RADIUS
server, for which you will already have user
accounts configured at this point. This
document does not describe how to set up
Administrative user accounts on the
RADIUS server. Please consult the
documentation for your RADIUS server for
these procedures.
5. Click “User Certificate” on the next page displayed.
