D-Link DWL-2200AP [16/192] Wireless client computers continued

Client Security Settings

Security should be disabled on the client used to do initial

configuration of the access point.

If the Security mode on the access point is set to anything

other than plain text, wireless clients will need to set a profile

to the authentication mode used by the access point and

provide a valid username and password, certificate, or similar

user identity proof. Security modes are Static WEP, IEEE 802.1x,

WPA with RADIUS server, and WPA-PSK.

For information on configuring security on the access point,

see the “Configuring Security” section in this manual.

Wireless Client Computers (continued)

Required Software

or Component

Description
