Default Settings (continued):
“Broadcast SSID and Security
Mode” in “Configuring
Security”
“Controlling Access by MAC
Address Filtering”
“Setting up Guest Access”
What the Access Point Does Not Provide
The D-Link DWL-2210AP is not designed to function as a gateway to the Internet. To
connect your wireless LAN (WLAN) to other LANs or to the Internet, you need a gateway
device.
Rate Sets (Mbps)
(Basic/Advertised
“Configuring Radio Settings”
• IEEE 802.1g: 11, 5.5, 2, 1
• IEEE 802.1b: 2, 1
Broadcast SSID
Allow
Security Mode
“Broadcast SSID and Security
Mode” in “Configuring
Security”
None (plain text)
Authentication Type None
MAC Filtering
Allow any station unless in list
Guest Login and
Management
Disabled
“Load Balancing”
Load Balancing
Disabled
“Configuring the Wireless
Distribution System (WDS)”
WDS Settings
None
Option Default Settings Related Information
