Step 3. Run KickStart Wizard (continued)
4. Go to the Access Point Administration Web pages by taking the link provided on the
KickStart page.
KickStart provides a link to the Administration Web pages via the IP address of the first
access point of each model. (For more information about model types and clustering see
“What Kinds of APs Can Cluster Together?” ) The Administration Web pages are a centralized
management tool that you can access via the IP address for any access point in a cluster.
Once your other access points are configured, you can also link to the Administration Web
pages by using the IP address for any of the other D-Link DWL-2210APs in a URL
(http://IPAddressOfAccessPoint).
Quick Steps for Setup
Step 4a. Log on to the Administration Web pages when
using Kickstart in a
DHCP network
When you follow the link from KickStart to the D-Link DWL-2210AP Administration Web
pages, you are prompted for a user name and password.
Enter the username and password and
click OK.
Field Default Setting
Field Default Setting
Username admin
Password admin
The user name is read-only.
It cannot be modified.
